Drive Axle for Forklifts

Forklift Drive Axle - A lift truck drive axle is actually a piece of machinery which is elastically fastened to a vehicle framework using a lift mast. The lift mast is attached to the drive axle and can be inclined round the drive axle's axial centerline. This is done by at least one tilting cylinder. Forward bearing elements together with back bearing components of a torque bearing system are responsible for fastening the drive axle to the vehicle framework. The drive axle can be pivoted around a swiveling axis oriented transversely and horizontally in the vicinity of the rear bearing parts. The lift mast could likewise be inclined relative to the drive axle. The tilting cylinder is attached to the vehicle frame and the lift mast in an articulated fashion. This allows the tilting cylinder to be oriented almost parallel to a plane extending from the swiveling axis to the axial centerline.

Model H35, H40, and H45 forklifts, that are made by Linde AG in Aschaffenburg, Germany, have a connected lift mast tilt on the vehicle frame itself. The drive axle is elastically connected to the frame of the forklift using many different bearings. The drive axle contains a tubular axle body along with extension arms attached to it and extend backwards. This particular kind of drive axle is elastically connected to the vehicle framework by rear bearing elements on the extension arms together with forward bearing devices located on the axle body. There are two rear and two front bearing devices. Each one is separated in the transverse direction of the lift truck from the other bearing tool in its respective pair.

The drive and braking torques of the drive axle are maintained through the back bearing components on the framework by the extension arms. The lift mast and the load generate the forces which are transmitted into the road or floor by the frame of the vehicle through the drive axle's anterior bearing parts. It is essential to ensure the components of the drive axle are constructed in a rigid enough way to be able to maintain immovability of the lift truck truck. The bearing parts can lessen small road surface irregularities or bumps all through travel to a limited extent and offer a bit smoother operation.
