Forklift Throttle Body
Forklift Throttle Body - Where fuel injected engines are concerned, the throttle body is the part of the air intake system that controls the amount of air that flows into the motor. This particular mechanism operates in response to driver accelerator pedal input in the main. Generally, the throttle body is positioned between the air filter box and the intake manifold. It is normally connected to or positioned next to the mass airflow sensor. The largest part in the throttle body is a butterfly valve referred to as the throttle plate. The throttle plate's main function is to be able to regulate air flow.
On many styles of vehicles, the accelerator pedal motion is communicated via the throttle cable. This activates the throttle linkages that in turn move the throttle plate. In vehicles consisting of electronic throttle control, also referred to as "drive-by-wire" an electric motor regulates the throttle linkages. The accelerator pedal is attached to a sensor and not to the throttle body. This sensor sends the pedal position to the ECU or Engine Control Unit. The ECU is responsible for determining the throttle opening based upon accelerator pedal position along with inputs from different engine sensors. The throttle body has a throttle position sensor. The throttle cable connects to the black part on the left hand side which is curved in design. The copper coil placed next to this is what returns the throttle body to its idle position when the pedal is released.
The throttle plate revolves in the throttle body each time the driver applies pressure on the accelerator pedal. This opens the throttle passage and allows much more air to be able to flow into the intake manifold. Normally, an airflow sensor measures this adjustment and communicates with the ECU. In response, the Engine Control Unit then increases the amount of fluid being sent to the fuel injectors to be able to generate the desired air-fuel ratio. Often a throttle position sensor or also called TPS is fixed to the shaft of the throttle plate to be able to provide the ECU with information on whether the throttle is in the wide-open throttle or otherwise called "WOT" position, the idle position or somewhere in between these two extremes.
In order to control the least amount of air flow while idling, some throttle bodies may have valves and adjustments. Even in units that are not "drive-by-wire" there would usually be a small electric motor driven valve, the Idle Air Control Valve or otherwise called IACV which the ECU utilizes to control the amount of air that could bypass the main throttle opening.
It is common that lots of automobiles contain one throttle body, although, more than one could be used and attached together by linkages to be able to improve throttle response. High performance vehicles like the BMW M1, along with high performance motorcycles like for instance the Suzuki Hayabusa have a separate throttle body for every cylinder. These models are called ITBs or otherwise known as "individual throttle bodies."
A throttle body is similar to the carburetor in a non-injected engine. Carburetors combine the functionality of the fuel injectors and the throttle body together. They function by blending the air and fuel together and by modulating the amount of air flow. Vehicles which include throttle body injection, that is known as CFI by Ford and TBI by GM, locate the fuel injectors in the throttle body. This allows an old engine the opportunity to be transformed from carburetor to fuel injection without really changing the engine design.
